LD- 3010 Kitchen Countertop Quartz CNC Router Center CNC Machine

Suitable for cabinets artificial stone, quartz stone countertops and sink, tea tray carving, European style edging, and other heterosexual stone, ceramics, glass and ceramic stone drilling, sanding, edge down, carving. 2D and 3D applications including kitchen tops, shower plates, tombstones, bas-reliefs, grooving and lettering.

Send Inquiry

Description

Technical Parameters

Countertop CNC Router Center Machine

3316 (4)

Countertop CNC Router Center Machine Specification

Model	LD-3316
Working area	*33001600400mm*
Machine size	*430026702360mm*
Positioning accuracy	±0.03/300mm
Re-position positioning accuracy	±0.03/300mm
Machine Table	30mm aluminum table
Drive system X,Y axis	gear rack
Drive system Z axis	ball screw
Guide rail	Taiwan HIWIN 30mm
Max power consumption	20-20.80kw
Max traverse speed	25000mm/min
Max working speed	15000mm/min
Spindle	15.8kw SACCARDO
Spindle speed	25000rmp
Tool magazine	24 tools
Tool holder	BT40
Reducer	Japan SHIMPO reducer
Working voltage	AC220V/380V
Command language	CAD
Interface	CF card, Ethernet
Operating system	SYNTEC 610MA-E5
Inverter	7.5kw HPMONT
Software	ARTCAM/Type3/UcancamV9

Countertop CNC Router Center Machine Application

- Suitable for kitchen tops quartz Countertop & sink drilling, sanding, edge down, carving, cabinets artificial stone,tea tray carving European style edging,

- besides 2D and 3D applications including shower plates, tombstones, bass-reliefs, grooving and lettering

Countertop CNC Router Center Machine Feature

- Whole machine is welded with seamless steel structure, with aging treatment.
- Adopt Taiwan HIWIN high precision linear orbit. X and Y axes adopt rack and pinion transmission, fast working, high efficiency . Z axis adopts Germany and Taiwan ball screw,with high precision and long life time.
- Well compatibility: CAD/CAM designing software e.g. Type 3/ Artcam/ Castmate/ Wentai etc.
- The function of re-carving after break point and power failure. Has the function of forecasting process time.
- Can choose updated DSP or Original Nc Studio control system.
- Perfect oil-inject system makes maintenance much easier.
- Good dust-collect function and Considerate Oil plate to keep the table always clean.
- We provide the DSP operating instruction in English, a set of cutters, software, necessary tools and accessories for free.

Countertop CNC Router Center Machine Samply

LD CNC products are exported to more than 70 countries & regions, products are widely used in sculpture, advertising, furniture, jewelry, packaging, materials of stone,wood, metal, acrylic, styrofoam, leather.
